- 【Wide Applications】- VONZOER Gas fence post driver is aimed to drive the pile into soft ground with great maneuverability and usability, widely used on many occasions such as piling, such as farm fencing, road reconstruction, garden renovation, agriculture and construction, etc.
- 【Sturdy & Durable】- The housing of the gasoline-driven rammer is made of plastic that has good toughness, excellent cooling vents for longer use. 【Note】It must use 2-stroke special oil. Equipped with 1 steel post driving head (ф60mm, ф80mm), not easy to rust and damage, ensures long-time use.
- 【High Performance】- With a maximum output of 2.5HP, fast rotation of 6500RPM and a maximum torque of 0.34kg-m/550RPM, this 2-stroke air-cooled gas powered post pounder can provide powerful impact force and impact frequency to achieve high efficiency, low fuel consumption and effort-saving.
- 【Smooth Operation】- This gasoline post driver uses a 2-stroke engine, which has a simple structure and works smoothly with little vibration. The premium housing and handle can greatly reduce the reaction force of the machine to ensure smooth operation.
- 【Main Parameters】- Displacement: 52CC; Fuel Tank Capacity: 1L (1.1Qt); Fuel Mixture Ratio: 25:1; Compression Ratio: 7.4: 1; Fuel Consumption Rate: 380 g/Ps.h; Tightening Torque Range: 550 – 1700 N.m (406 – 1250 Ft.Lbs); Clutch Speed: 1200RPM; Ignition System Method: Hand Pull Start; Tightening Torque: 550-1030Nm; Height: 71cm (28inch)
Description
Two-stroke gas-powered motor with simple structure and 52cc displacement provides powerful power performance without the need for electricity and easy to use, improving efficiency and saving labor.
Details
Two-stroke Engine: This gasoline-driven rammer uses a two-stroke engine, which has a simple structure and works smoothly with little vibration.
Plastic Housing: The housing of the gasoline-driven rammer is made of plastic that has good toughness, so it is more durable and can be used for a long time.
Application
This gas powered pile driver can be used for piling, trenching, rock breaking, ramming.
Specification
Engine Type: 2-Stroke, Cold Air, Single Cylinder
Displacement: 52CC
Fuel Tank Capacity: 1L (1.1Qt)
Fuel Mixture Ratio: 25:1
Number Of Revolutions (Idling): 2700RPM -250
Number Of Revolutions (Loading): 7120RPM
Number Of Revolutions (Maximum): 9880RPM
Maximum Output: 2.5HP(1900W) 6500RPM
Maximum Torque: 0.34kg-m/550RPM
Compression Ratio: 7.4: 1
Fuel Consumption Rate: 380 g/Ps.h
Tightening Torque Range: 550 – 1700 N.m (406 – 1250 Ft.Lbs)
Clutch Speed: 1200RPM
Ignition System Method: Hand Pull Start Ignition
Spark Plug Model: Ngk Bpmr6A
Carburetor Type: Diaphragm Type
Tightening Torque: 550-1030Nm
Height: 71cm (28inch)
Body Size: 32x50x26cm (12.6x19.7x10.2 inch)
Overall Dimensions: 74x34x26cm (29.1x13.4x10.2 inch)
Impact Part Output Square Shaft Size: 2.54cm (1inch)
Piling Head Diameter: 6cm (2.4inch) 8cm(3.1inch)
Net Weight: 13kg (28.7lb)
Package Includes
1x T-Post Driver Machine
1x Piling Head
1x Proportioning Pot
1x Funnel
1x Tool Kit
Note
It must use 2-stroke special oil.
